FP25R12W2T7 Infineon IGBT Module

Name: FP25R12W2T7 Infineon IGBT Module
Brand: MICROCHIP TECHNOLOGIES
Price: 4500.0 INR
Availability: InStock

Price 4500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

FP25R12W2T7 Infineon IGBT Module Specification

Features
Low saturation voltage loss, high reliability, easy mounting, low inductance design

Power Supply
Electric

Output
AC / DC (as per inverter configuration)

Components
IGBTs, diode freewheeling, integrated thermistor

Power Source
External DC power supply

IP Rating
Unsealed, conformal coating recommended

Interface
Press-fit or solder pin interface

Thermal Conductivity
High thermal conductivity ceramic baseplate

Input
DC

Sensors Specification
Integrated thermistor for temperature measurement

Operating Temperature
-40C to +150C

Usage
Industry / Power Control

Response Time
Fast switching, <1 s

Product Type
IGBT Module

Application
Industrial Drives, Inverter, Motor Control, Power Supply

Rated Voltage
1200 V

Supply Voltage
Up to 1200 V

Size
Standard compact IGBT module size

Dimension (L*W*H)
104.15 mm x 62 mm x 30 mm (approx.)

Function
IGBT Inverter Module

Color
White / Off-white (Module body)

Weight
Approx. 150 g

Thickness
Module body thickness approx. 12 mm

Current Rating
25 A

Capacity
25 A

Frequency
Up to 20 kHz switching frequency

Module Polarity
Half-bridge configuration

Isolation Voltage
2500 V AC (1 min)

IGBT Technology
Trench and Field Stop (Trenchstop) technology

Compliance
RoHS Compliant

Collector-Emitter Voltage (Vces)
1200 V

On-State Voltage Drop (Vce(sat))
~1.75 V (at Tc = 25C, Ic = 25A)

Mounting Type
Screw and press-fit mounting possible

Collector Current (Ic)
25 A (nominal)

Reverse Voltage (Vr)
1200 V (diode)

Package
W2-T7 standard package

Heat Sink
Required, not included

Surge Current
50 A (1 ms, half-sine)

Gate-Emitter Voltage (Vge)
+/-15 V (max)

Module Type
Dual IGBT Module

Short Circuit Withstand Time
10 s (typical)

FP25R12W2T7 Infineon IGBT Module Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About FP25R12W2T7 Infineon IGBT Module

Experience elite performance and world-class efficiency with the FP25R12W2T7 Infineon IGBT Module. Combining fresh innovation with renowned Trenchstop technology, this dual-module is engineered for reliability and outstanding power handling. Ideal for industrial power control, it features a limited-time offering of brilliant features, including high thermal conductivity, rapid switching, and robust surge capabilities. Its compact W2-T7 standard package, screw and press-fit mounting, and RoHS compliance make it a superb choice for demanding applications in motor control, drives, and inverter systems.

Versatile Industrial Advantage with Elite Material

The FP25R12W2T7 offers a distinct commercial advantage for industries seeking reliability and performance. Its robust half-bridge configuration and Trenchstop IGBT technology enable superior power conversion for inverters, industrial drives, and motor control systems. Built with high-quality materials, it boasts easy mounting, low inductance, and an integrated thermistor for temperature monitoring. This advances operational safety and efficiency, ensuring your enterprise gets the advantage of brilliant engineering and sustainable performance in every application.

Streamlined Delivery, Competitive Supply, and Market Reach

The FP25R12W2T7 is delivered efficiently across India, with reasonable expenditure ensuring added value for commercial projects. Supply ability is maintained through a strong distributor and importer network, giving customers a reliable estimate on availability. With prompt delivery timelines and a strong presence in the main domestic market, customers benefit from fast access and excellent after-sales support. Your purchase is expedited for minimal downtime and maximum productivity, meeting industry requirements and project deadlines.

FAQ's of FP25R12W2T7 Infineon IGBT Module:

Q: How does the FP25R12W2T7 module benefit industrial applications?

A: The FP25R12W2T7 enhances industrial operations by providing high efficiency, reliable power switching, and excellent thermal management, making it ideal for inverters, industrial drives, and motor controls.

Q: What is the mounting process for this IGBT module?

A: The module is designed for both screw and press-fit mounting, offering flexibility for integration into various system layouts and ensuring solid mechanical connections.

Q: When should I use a heat sink with this module?

A: A heat sink is required for thermal management during operation to maintain optimal performance, as the module is designed for high-power applications.

Q: Where is this module primarily supplied and delivered?

A: FP25R12W2T7 modules are supplied and delivered across India, targeted towards key industrial hubs through an established distributor and importer network.

Q: What are the material features that ensure the module's durability?

A: The module features a high thermal conductivity ceramic baseplate, integrated thermistor, and robust half-bridge configuration, ensuring durability and reliable thermal performance over extended use.

Q: How fast can I expect delivery after placing an order?

A: Delivery times are efficiently managed with timely dispatch. Customers can request an estimate on specific delivery dates based on current stock and supply chain logistics.
