IRKD 105/16 high-power thyristor/diode module SCR IGBT module

Send Inquiry

Request To Call Back

IRKD 105/16 high-power thyristor/diode module SCR IGBT module

Name: IRKD 105/16 high-power thyristor/diode module SCR IGBT module
Brand: MICROCHIP TECHNOLOGIES
Price: 800.0 INR
Availability: InStock

Price 800.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

IRKD 105/16 high-power thyristor/diode module SCR IGBT module Specification

Interface
Screw terminal connections

Response Time
Fast commutation (typical for SCR modules)

Features
Industrial grade, high surge capability, robust design, screw terminal, isolated mounting base

IP Rating
IP00 (open device, requires enclosure)

Usage
Power control, Rectifiers, Inverters, AC/DC drives

Input
Control signal for gate triggering (thyristor), line voltage

Thermal Conductivity
High (integrated metal base for heat dissipation)

Power Source
External power circuit

Power Supply
External DC source (as per application)

Components
Thyristor/Diode chips, base plate, terminals, insulation

Operating Temperature
-40C to +125C (junction)

Output
Rectified or controlled AC/DC power

Product Type
High-Power Thyristor/Diode (SCR/IGBT) Module

Application
Industrial power electronics, Motor drives, Power rectification units

Rated Voltage
1600V

Supply Voltage
Up to 1600V

Size
Standard compact module

Dimension (L*W*H)
140mm x 62mm x 35mm (approximate)

Function
High-power rectification and switching

Color
Black module body with metal mounting base

Weight
Approx. 950g

Current Rating
105A

Thickness
Module thickness ~35mm

Capacity
105A continuous current

Frequency
50/60 Hz

Storage Temperature
-40C to +150C

Reverse Voltage (VRRM)
1600V

Insulation Voltage
2500V RMS (base to terminals)

Mounting Type
Panel/Chassis mount with screws

Creepage Distance
17mm (approximate)

Isolation Baseplate
Yes, electrically isolated

Case Material
Thermoplastic case with metal base

Peak Surge Current (ITSM)
2100A (10ms half-sine wave)

Gate Trigger Current (IGT)
Max. 150mA

Compliance
RoHS

IRKD 105/16 high-power thyristor/diode module SCR IGBT module Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About IRKD 105/16 high-power thyristor/diode module SCR IGBT module

Discover a sizzling clearance bargain with the IRKD 105/16 high-power thyristor/diode module-an unrivaled solution for industrial power control and rectification needs! This remarkable SCR IGBT module boasts a triumphant 2100A peak surge current (10ms half-sine wave), robust 2500V RMS insulation voltage, and a superior 1600V reverse voltage rating. Engineered with a thermoplastic case, metal mounting base, and RoHS compliance, it delivers electrically isolated mounting, remarkable durability, and high thermal conductivity. Designed for panel or chassis mounting, this compact module excels in motor drives, power control, and rectifier applications.

Ideal for Industrial Power & Rugged Applications

The IRKD 105/16 high-power thyristor/diode module is a formidable choice for industrial power electronics, including motor drives, rectification units, and inverter surfaces. Its core material features a thermoplastic body with a metal base, ensuring high thermal conductivity for superior heat dissipation. The panel/chassis mount application surface, paired with secure screw terminals, makes installation effective even in demanding industrial environments, guaranteeing reliable and long-lasting performance.

Packing, Dispatch & Outlay: Seamless Ordering Experience

Orders for the IRKD 105/16 high-power module are expertly processed for swift packing and dispatch from the preferred Indian FOB port. Main domestic markets include major industrial hubs across India, ensuring prompt order completion. Payment terms are flexible for customer convenience, optimizing your outlay for value and efficiency. Each shipment is securely packed, guaranteeing the module's safe arrival and the continuity of your industrial projects.

FAQ's of IRKD 105/16 high-power thyristor/diode module SCR IGBT module:

Q: How does the IRKD 105/16 module benefit industrial power applications?

A: The IRKD 105/16 module delivers high current-handling capacity (105A continuous, 2100A surge), fast commutation, and robust insulation, making it ideal for industrial motor drives, power rectifiers, and inverter systems.

Q: What materials and design features ensure the module's reliability?

A: Constructed with a thermoplastic case, metal mounting base, and an isolation baseplate, the module offers excellent thermal conductivity, electrical isolation, and RoHS compliance for safe, reliable performance.

Q: Where can I install the IRKD 105/16 thyristor/diode module?

A: This module is designed for panel or chassis mounting using screw terminals, suitable for power control surfaces in industrial environments, AC/DC drives, and rectification panels.

Q: What is the packing and order completion process for this module?

A: After order confirmation, the IRKD 105/16 module is packed securely and dispatched from a main Indian FOB port. Order completion is efficient to maintain project timelines.

Q: Which main domestic markets are supplied with this module?

A: The IRKD 105/16 module is distributed throughout industrial hubs across India, servicing regional manufacturers, suppliers, and power system integrators.

Q: What payment terms and outlay options are available?

A: Flexible payment terms are available to accommodate business needs, ensuring a smooth purchasing experience and optimal outlay management for customers.
