GD600HFY120C2S STARPOWER DUAL IGBT MODULE

Name: GD600HFY120C2S STARPOWER DUAL IGBT MODULE
Brand: MICROCHIP TECHNOLOGIES
Price: 6000.0 INR
Availability: InStock

Price 6000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GD600HFY120C2S STARPOWER DUAL IGBT MODULE Specification

IP Rating
IP00

Response Time
Fast switching response

Input
DC/Electrical signal

Usage
Industrial power electronics, inverter circuits, motor drives

Thermal Conductivity
Optimized for high power dissipation with insulated baseplate

Power Source
External electric supply

Output
Controlled electrical output

Interface
Screw terminal & plug connection

Features
Pressure contact technology, low VCE(sat), integrated free wheeling diode, high reliability

Operating Temperature
-40C to +150C (junction temperature)

Components
IGBT chips, fast recovery diode, encapsulated module

Power Supply
Electric

Product Type
Dual IGBT Module

Application
AC drives, UPS, renewable energy systems, power supplies, welding equipment

Rated Voltage
1200V

Supply Voltage
1200V

Size
Standard module size (see dimensions)

Dimension (L*W*H)
134 mm x 62 mm x 30 mm (Approx.)

Function
Switching and controlling power in industrial applications

Color
Black / Silver

Weight
Approx. 1050g

Capacity
600A

Current Rating
600A

Thickness
Standard module thickness (see dimensions)

Frequency
High-frequency switching (depends on application)

Package
Encapsulated Industrial Module

Collector-Emitter Saturation Voltage VCE(sat)
Typical 2.15V at 600A, 25C

Baseplate Material
Copper (nickel plated)

Polarity
Dual, Symmetrical

Collector Power Dissipation
2300W

Internal Diode
Yes, fast recovery type

Gate Emitter Voltage
20V (max)

Gate Threshold Voltage VGE(th)
6.0 ~ 8.0V

Isolation Voltage
2500V AC (1 min)

Dielectric Strength
High, per industrial standards

Storage Temperature
-40C to +125C

Module Structure
Dual IGBT with fast recovery diode

Model Number
GD600HFY120C2S

Mounting Type
Chassis Mount / Panel Mount

RoHS Status
Compliant

GD600HFY120C2S STARPOWER DUAL IGBT MODULE Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About GD600HFY120C2S STARPOWER DUAL IGBT MODULE

Take control with the imposing GD600HFY120C2S STARPOWER Dual IGBT Module, a must-have for high-powered industrial electronic applications. Jump on superior performance-this illustrious module boasts a towering 1200V rating and 600A capacity, encapsulating state-of-the-art IGBT chips and a fast-recovery diode for optimal efficiency. The robust pressurized copper baseplate ensures unrivaled thermal conductivity, while isolating up to 2500V AC. RoHS compliant and designed for reliability, Try Now and elevate your inverter circuits, motor drives, and renewable power platforms to the next level.

Powerful Features & Versatile Applications

The GD600HFY120C2S module stands out with pressure contact technology, low VCE(sat), and rapid switching. Integrated with a fast recovery diode and nickel-plated copper baseplate, it ensures high reliability and long operational life. Commonly applied in AC drives, UPS, power supplies, welding equipment, and renewable energy, it also enhances heavy plant machinery by ensuring efficient, stable power control. This makes it impressively adaptable across various demanding industrial sectors.

Shipping, Payment & Packaging Insights

The GD600HFY120C2S STARPOWER Dual IGBT Module is typically handed over at major FOB ports in India to ensure secure and prompt arrival. Payment terms are flexible, minimizing upfront expenditure for importers and distributors. Packaging details focus on protective encapsulation, safeguarding the module throughout transit. Whether bulk orders or individual shipment, every module is carefully prepared to maintain its illustrious performance upon delivery.

FAQ's of GD600HFY120C2S STARPOWER DUAL IGBT MODULE:

Q: How does the GD600HFY120C2S benefit industrial applications?

A: The GD600HFY120C2S delivers efficient, reliable switching and power control ideal for inverters, AC drives, UPS systems, and welding equipment, enhancing performance and operational stability.

Q: What features make this module a must-have for power electronics?

A: Key features like pressure contact technology, low collector-emitter saturation voltage, high-speed switching, and an integrated fast recovery diode ensure high reliability and superior thermal management.

Q: Where can the GD600HFY120C2S module be installed?

A: It can be mounted on a chassis or panel, integrating seamlessly into diverse industrial environments, such as power supply units, renewable energy systems, or heavy plant machinery.

Q: How is the GD600HFY120C2S protected during shipment?

A: Each module is encapsulated and packaged in protective materials to maintain integrity and functionality during transit, ensuring safe and secure delivery to the customer.

Q: What is the process for purchasing this module?

A: Orders can be placed through certified distributors or directly with suppliers. Payment terms are agreed upon to suit the customer, and the shipment is handed over at designated FOB ports in India.

Q: When should I consider upgrading to the GD600HFY120C2S module?

A: Upgrade when your current system requires higher voltage capacity, improved thermal management, or faster and more reliable power switching for critical industrial tasks.
