GD100SGY120D6S IGBT Power Module StarPower

Name: GD100SGY120D6S IGBT Power Module StarPower
Brand: MICROCHIP TECHNOLOGIES
Price: 2000.0 INR
Availability: InStock

Price 2000.0 INR/ Unit

Get a Price/Quote

MOQ : 2 Units

GD100SGY120D6S IGBT Power Module StarPower Specification

Response Time
Fast switching (<1s turn-on/turn-off)

Thermal Conductivity
Optimized copper baseplate for efficient heat dissipation

Input
Control input via gate terminal

Power Supply
Electric

IP Rating
IPM-type encapsulation

Components
IGBTs, freewheeling diodes, thermal pad

Operating Temperature
-40C to +150C

Features
Low saturation voltage, high reliability, short-circuit withstand time, integrated protection

Output
High-voltage DC/AC switching output

Usage
Industrial motor drives, inverters, UPS, servo drives

Power Source
External electrical supply

Interface
Screw terminal

Product Type
IGBT Power Module

Application
Industrial automation, power electronics

Rated Voltage
1200V

Supply Voltage
Up to 1200V

Size
Standard module size

Dimension (L*W*H)
106mm x 61.5mm x 32mm

Function
Switching and amplification in inverter and converter circuits

Color
Black

Weight
Approx. 330g

Capacity
100A

Current Rating
100A

Thickness
32mm

Frequency
DC to 20kHz typical

Short-Circuit Withstand Time
10s

Cooling
Forced air or heatsink required

Typical Gate Charge
260nC

Internal Circuit
6-pack module (three-phase bridge configuration)

Isolation Voltage
2500V AC (1 min) between terminals and baseplate

Series
GD100SGY120D6S

Continuous Collector Current (Ic)
100A

Collector Emitter Voltage (Vces)
1200V

Turn-on/Turn-off Loss
7.6mJ / 6.1mJ (typical at 25C, Vce=600V, Ic=100A)

Case Material
Plastic encapsulated with isolated metal base

Collector Dissipation (Pc)
375W

RoHS Compliance
Yes

Gate-Emitter Voltage (Vge)
20V max

Mounting
Screw mounting

Package Type
Module

GD100SGY120D6S IGBT Power Module StarPower Trade Information

Minimum Order Quantity
2 Units

Supply Ability
100 Units Per Month

Delivery Time
7 Days

About GD100SGY120D6S IGBT Power Module StarPower

Jump on the opportunity to experience world-class performance with the GD100SGY120D6S IGBT Power Module by StarPower. Designed for outstanding reliability and efficiency, this splendid 6-pack three-phase bridge module operates at 1200V and 100A, making it perfect for industrial motor drives, inverters, UPS, and servo drives. Select this module for its robust 2500V AC isolation, superior thermal dissipation, and integrated protection features. With RoHS compliance, optimized copper baseplate, and easy screw mounting, this module is available for a limited time to all distributors, importers, and suppliers in India.

Outstanding Features and Competitive Edge of GD100SGY120D6S IGBT Module

The GD100SGY120D6S IGBT Power Module StarPower delivers exceptional efficiency in switching and amplification for inverter/converter circuits. Its special features include low saturation voltage, fast response time, and high short-circuit withstand, ensuring top-notch reliability and protection. Primarily used in industrial automation and power electronics, its competitive advantages are the standard size, easy mounting, isolated metal base, and RoHS compliance. Clients benefit from its outstanding thermal conductivity and long operational lifespan, making it a preferred choice in demanding environments.

FOB Port, Sample Availability, and Supply Details for GD100SGY120D6S

Premium customers can request samples of the GD100SGY120D6S module from our designated FOB ports. The asking price will be provided upon inquiry to ensure competitive and transparent rates. Samples, once approved, are dispatched promptly by our team. We maintain a robust supply ability for both small and large volume orders, ensuring timely delivery for distributors and suppliers. Select this module to secure advance shipments and jump ahead in the industrial automation market with StarPower technology.

FAQ's of GD100SGY120D6S IGBT Power Module StarPower:

Q: How can the GD100SGY120D6S IGBT Power Module be used in industrial applications?

A: The module is ideal for use in industrial motor drives, inverters, UPS systems, and servo drives, providing reliable high-voltage switching and amplification.

Q: What are the primary benefits of choosing this IGBT Power Module?

A: It offers outstanding reliability, low saturation voltage, rapid response time, high short-circuit withstand time, and efficient thermal management for superior performance in power electronics.

Q: When can customers expect the dispatched product after placing an order?

A: Products are typically dispatched promptly after order confirmation, ensuring minimal delays in supply and reliable delivery schedules.

Q: Where is the GD100SGY120D6S module supplied from, and do you offer FOB options?

A: The modules are supplied from designated FOB ports, with flexible shipping arrangements available for both domestic and international customers.

Q: What is the process to request samples or get the asking price for bulk orders?

A: Customers can contact our sales team to request samples or inquire about the asking price for bulk quantities, after which samples and quotations are provided quickly.
