FF450R12KT4 Infineon IGBT Module

Name: FF450R12KT4 Infineon IGBT Module
Brand: MICROCHIP TECHNOLOGIES
Price: 7000.0 INR
Availability: InStock

Price 7000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

FF450R12KT4 Infineon IGBT Module Specification

Product Type
IGBT Module

Supply Voltage
Up to 1200V

Dissipation Power
2100W

Operating Temperature
-40C to +150C

Power Consumption
Depends on load, maximum module rating 450A

Temperature Range
-40C to +150C

Input Voltage
1200V

Voltage Regulator Type
N/A (IGBT Power Module)

Size
Length: 134mm; Width: 62mm; Height: 30mm

Weight
Approximately 470g

Internal Diode
Yes (Anti-parallel fast recovery diodes)

Package Type
EconoDUAL 3

Collector Current (Ic, nominal)
450A

Insulation Voltage
4000Vrms

Configuration
6-Pack (Three Phase Bridge)

Mounting Type
Screw Mount

Collector Emitter Voltage (Vces)
1200V

Technology
Trench Stop IGBT 4th Generation

Gate Emitter Voltage (Vge)
20V (recommended 15V)

Switching Frequency
Up to 20 kHz

FF450R12KT4 Infineon IGBT Module Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

FF450R12KT4 Infineon IGBT Module About

Experience resplendent performance with the FF450R12KT4 Infineon IGBT Module, engineered to deliver prodigious results for elite industrial applications. Offering a formidable 1200V collector-emitter voltage and ace current handling at 450A, this 6-pack EconoDUAL 3 module features fourth-generation Trench Stop technology for superior efficiency and switching at frequencies up to 20 kHz. With robust insulation (4000Vrms), an anti-parallel fast recovery diode, and customizable integration options, this screw-mount unit excels in motor drives, inverters, power supplies, and renewable energy systems-all at competitive pricing for distributors, importers, and suppliers in India.

Versatile Applications and Usage Directions

The FF450R12KT4 module is ideal for high-performance requirements in inverters, power supplies, motor drives, and renewable energy generation. Its internal fast recovery diode and robust thermal design ensure reliability in demanding environments, spanning industrial automation, wind turbines, and solar systems. For optimal use, maintain recommended gate-emitter voltage settings and secure with its screw-mount design, ensuring stable operation throughout its wide temperature range. Consult technical datasheets for application-specific customization and setup guidance.

Supply Ability and Sample Policy Insights

Our FF450R12KT4 Infineon IGBT Modules are shipped promptly across India, meeting both small and prodigious order needs. Benefit from competitive pricing, including sample units available at the lowest price or at standard list price, depending on policy. Distributors and suppliers can request samples to evaluate product performance before bulk orders. Our streamlined supply process ensures timely delivery, supporting rapid prototyping and full-scale deployment for your advanced power module requirements.

FAQ's of FF450R12KT4 Infineon IGBT Module:

Q: How can the FF450R12KT4 IGBT Module be customized for specific applications?

A: The FF450R12KT4 module can be tailored through choice of suitable gate driver circuits, optimized thermal management strategies, and specific mounting configurations, allowing it to be adapted seamlessly for use in various inverter, motor drive, or renewable energy settings.

Q: What are the recommended steps for installing and using this module?

A: Begin by securing the module with the provided screw mounts, ensuring good thermal contact with heat sinks. Use the recommended gate-emitter voltage of 15V (with a maximum of 20V), and refer to application notes for wiring and protection guidelines to guarantee safe, reliable operation.

Q: Where is the FF450R12KT4 commonly used?

A: This module finds extensive use in industrial motor drives, power supply units, inverter systems, and renewable energy projects such as wind and solar power converters, thanks to its high efficiency and robust design.

Q: What benefits does the Trench Stop IGBT 4th Generation technology offer?

A: Trench Stop IGBT 4th Generation technology enables higher switching frequencies, reduced power losses, and improved thermal characteristics, resulting in greater system efficiency and reliability for demanding applications.

Q: How does the sample policy work for distributors and suppliers in India?

A: Distributors and suppliers may request sample modules, which are shipped either at a discounted rate or the standard list price, based on current policy. This enables hands-on evaluation before proceeding to larger or bulk purchases.
