SKD 210/18 SEMIKRON MODULE

About SKD 210/18 SEMIKRON MODULE

• Manufacturer: Mitsubishi Electric
• Part Number: CM100RX1-24A
• Type: IGBT Power Module
• Configuration: Single IGBT with anti-parallel diode
• Mounting: Chassis mount (baseplate)


Engineered for Demanding Applications

The SKD 210/18 SEMIKRON MODULE is crafted to deliver exceptional performance in environments requiring reliable AC to DC conversion. Its high surge current capability and wide temperature tolerance ensure steady operation in power supply units, industrial drive systems, and uninterruptible power supplies.


Rugged, Reliable Design

Featuring industrial-grade plastic and metal construction, the module offers robust dielectric strength and isolation for enhanced safety. Screw-mount installation allows for secure and straightforward integration into existing setups, while its compliance with RoHS ensures eco-friendly utilization.


High Efficiency & Long-Term Stability

This SCR module consistently delivers high power output with a maximum forward current of 210A and low forward voltage drop, minimizing energy losses. With a dissipation power of 200W and reverse current limited to 10mA at 25C, it is designed for reliable, long-term industrial performance.



FAQ's of SKD 210/18 SEMIKRON MODULE :




Q: How is the SKD 210/18 SEMIKRON MODULE typically installed in industrial systems?

A: The module uses a secure screw-mount design, allowing for easy and reliable installation into power supply units, industrial drives, and UPS systems. This simplifies maintenance and integration, making it suitable for both new and replacement projects.



Q: What are the primary benefits of using this SEMIKRON module in AC to DC conversion applications?

A: Its high surge current rating (3500A), wide temperature operating range (-40C to +125C), and excellent power handling (up to 210A forward current) provide dependable performance in demanding environments. This leads to improved system stability and longevity.



Q: When should I consider using the SKD 210/18 module in my power electronics project?

A: This module is ideal when your application requires robust AC to DC conversion, high surge capability, and efficient operation over a broad temperature range-especially in industrial power supply or backup systems.



Q: Where is the SKD 210/18 SEMIKRON MODULE commonly used?

A: It finds widespread use in industrial drives, power supply units, and uninterruptible power supply (UPS) systems, mainly within commercial and industrial settings requiring high reliability and power density.



Q: What makes the SKD 210/18 module compliant with industry safety and environmental standards?

A: This module is RoHS compliant, ensuring it meets environmental regulations by restricting hazardous substances. Its 2500V AC dielectric and isolation voltage also enhance operational safety in industrial installations.



Q: How does the module maintain reliable performance over time?

A: With a robust construction, low reverse current (10mA at 25C), and sturdy packaging materials, the module ensures consistent operation and resists thermal and electrical stress even in harsh environments.
